BACHMANN Twist 2 Round 2x Power Sockets Matt White

Round metallic cover lid, white matt, similar to RAL9010.

$216

Wishlist Wishlist Wishlist
SKU946.200 Categories, Tag
Close
Additional information
Brand

Close
Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “BACHMANN Twist 2 Round 2x Power Sockets Matt White”

Your email address will not be published. Required fields are marked *

Cancel

Close
Product Data Sheets

Product Sheet

Download

Installation Manual

Download

The socket module 946.200 from Bachmann is made in a metal case, equipped with 2 electrical sockets of the Schuko standard, and has a modern design of the TWIST2 range.

Product Features

-Bachmann twist 2 946.100 built-in sockets round color matt black.
-Nice double socket to build in, for example, your desk or countertop.
-By pressing the “button” in the middle, the sockets are opened mechanically.
-Supplied as standard with a 2-meter power cable.
-Installation size around 105mm.
-Built-in height 40mm.

Key features of the Bachmann Twist 2 plug-in modular socket

-Automatic opening mechanism with integrated damper triggered by pressing the button in the center of the built-in multi-socket cover;
-Fast charging of end devices thanks to the powerful 22-watt USB A/C charger;
-No annoying fingerprints thanks to the high-quality surfaces with an anti-fingerprint coating;
-Removable cover in two different shapes, round or square, for easy and comfortable cleaning

Technical Data

-The socket block is designed for installation on a flat surface with a depth of 45 mm. Suitable for countertop thickness (panel): 20-40mm.
-Block with sockets equipped with a wire with a plug (2 meters).
-The design of the electrical outlet has special protective shutters to protect it from children.
-Rated current: 16A
-Color: White opaque.
-Dimensions: 115×40 mm Embedding
-depth: 40 mm
-Worktop thickness: min. 8 mm
-Block diameter: 115 mm.
-Embedding diameter: 105 mm
